Input Current (mA)

Operating Voltage (V)

Condition

1.0

5

--

1.

Contact Rating

10mA, 5VDC

2.

Contact Resistance

10Ω max.

3.

Operation Diagram

Refer to Fig. 1

4.

Insulation Resistance

1000MΩmin.,100VDC

5.

Dielectric Strength

500VDCmin.,1minute

6.

Capacitance

5pF max.

7.

Conductive Rate

85% min.

Test Item

                       Contents

1

IR Reflow

Peak temp.=255~260°C

2

Operating Temperature

-25°C~ 85°C

3

Storage Temperature

-40°C~ 85°C

4

Humidity

40 °C/ 95 %RH

5

Mechanical Life

2 Hz horizontal

1,000,000 times

6

Electrical Life

100,000 times
